TP-LINK Gigabit Smart Switch TL-SG2008 is equipped with 8 gigabit RJ45 ports. The switch provides high performance, enterprise-level QoS, useful security strategies and rich layer 2 management features
TP-LINKs 8-Port Gigabit Smart Switch TL-SG2008 is especially designed for the small and medium business networks that require efficient network management. TL-SG2008 comes with a comprehensive set of features, such as Link Aggregation Group, 802.1Q VLAN, Access Control Lists (ACL), Quality of Service(QoS L2 to L4), Storm Control and IGMP Snooping to provide a small or medium-sized business with a network that is geared for growth while ensuring performance and reliability. Whats more, its easy-to-use web management interface means faster setup and configuration with less downtime, providing the ideal solution for your business network
To integrate voice, data and video service on one network, the switch applies rich QoS policies. Administrator can designate the priority of the traffic based on a variety of means including Port Priority, 802.1P Priority and DSCP Priority, to ensure that voice and video are always clear, smooth and jitter free.In conjunction with the Voice VLAN the switch supports, the voice applications will operate with much smoother performance
For more application of layer 2 switches, TL-SG2008 supports a complete lineup of layer 2 features, including 802.1Q tag VLAN, Port Isolation, Port Mirroring, STP/RSTP/MSTP; Link Aggregation Control Protocol and 802.3x Flow Control function. Any more, the switches provide advanced features for network maintenance such as Loop Back Detection, Cable Diagnostics and IGMP Snooping. IGMP Snooping ensures the switch intelligently forward the multicast stream only to the appropriate subscribers while IGMP throttling and filtering restrict each subscriber on a port level to prevent unauthorized multicast access
TL-SG2008 is easy to use and manage. It supports various user-friendly standard management features, such as intuitive web-based Graphical User Interface(GUI) or industry-standard Command Line Interface(CLI). SNMP (v1/2/3) and RMON support enables the switch to be polled for valuable status information and send traps on abnormal events
Gigabit Ethernet connections on all ports provide full speed of data transferring
Integrated security strategy including 802.1Q VLAN, ACL, Port Security and Storm control help protect LAN area investment
L2/L3/L4 QoS and IGMP snooping optimize voice and video applications
WEB/CLI managed modes, SNMP, RMON bring abundant management features
Innovative energy-efficient technology saves up to 65% of power consumption
Layer 2 Features -
Static Link Aggregation/ Link Aggregation Control Protocol (LACP)
Up to 512 VLANs simultaneously(out of 4K VLAN IDs)
STP/RSTP/MSTP
IGMP Snooping
Quality of Service -
4 priority queues
Support IEEE 802.1P
DSCP QoS
Rate limit feature
Security Strategies -
Access Control List (L2~L4 ACL)
IP-MAC-Port Binding
802.1x and Radius Authentication
Port Security
Storm Control
SSL and SSH encryptions
Dos Defend
Management -
Web-based GUI
Command Line Interface(Telnet)
SNMP v1/v2c/v3
RMON (1, 2, 3, 9 group)
HARDWARE FEATURES
Standards and Protocols, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
Interface, 8 10/100/1000Mbps RJ45 Ports, (Auto-Negotiation/Auto MDI/MDIX)
Fan Quantity, Fanless
Dimensions, 209(W) x 126(D) x 26(H)mm
PERFORMANCE
Bandwidth/Backplane, 16Gbps
Packet Forwarding Rate, 11.9Mpps
MAC Address Table, 8k
Jumbo Frame, 9216 Bytes
SOFTWARE FEATURES
L2 Features, IGMP Snooping V1/V2/V3, 802.3ad LACP (Up to 6 aggregation groups, containing 4 ports per group), Spanning Tree STP/RSTP/MSTP, BPDU Filtering/Guard, TC/Root Protect, Loop back detection, 802.3x Flow Control
VLAN, Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs)
Access Control List, L2 to L4 package filtering based on source and destination, MAC address, IP address, TCP/UDP ports, 802.1p, DSCP, protocol and VLAN ID, Time Range Based
Security, SSH v1/v2, SSL v2/v3/TLSv1, Port Security, Broadcast/Multicast/Unknown unicast Storm Control, 802.1x and Radius Authentication, IP-Mac-Port-VID Binding, ARP Inspection, DHCP Snooping, DoS Defend
OTHERS
Certification, CE, FCC, RoHS
Package Contents, TL-SG2008, Power Adapter, Installation Guide, Resource CD, Rubber Feet
System Requirements, Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, NetWare, UNIX or Linux
